參數：
產品結構：雙扣型
產品材質：不銹鋼
表面處理：白色(黑色)PVC披覆
規(guī)格表：
| 型號 | 英寸 | 內徑 (mm) | 外徑 (mm) | 披覆后外徑 (mm) | 包裝(m/roll) |
|---|---|---|---|---|---|
| P040070C2K1 | - | 4.0±0.2 | 6.0±0.2 | 7.0±0.25 | 200 |
| P046080C2K1 | - | 4.6±0.2 | 6.6±0.2 | 8.0±0.25 | 200 |
| P050080C2K1 | - | 5.0±0.2 | 7.0±0.2 | 8.0±0.25 | 200 |
| P054095C2K1 | - | 5.4±0.2 | 7.8±0.2 | 9.5±0.25 | 100 |
| P059100C2K1 | - | 5.9±0.2 | 8.4±0.2 | 10.0±0.25 | 100 |
| P066100C2K1 | - | 6.6±0.2 | 9.0±0.2 | 10.0±0.25 | 100 |
| P095150C2P1 | 1/4 | 9.5±0.2 | 12.5±0.2 | 15.0±0.25 | 100 |
| P100150C2P1 | - | 10.0±0.2 | 12.5±0.2 | 15.0±0.25 | 100 |
| P125177C2P1 | 3/8 | 12.5±0.3 | 15.7±0.3 | 17.7±0.35 | 50 |
| P161213C2P1 | 1/2 | 16.1±0.3 | 19.5±0.3 | 21.3±0.35 | 50 |
