參數：
材質：PA66 (UL94 V-0), PA6 (UL94 V-2)
螺牙選擇：NPT, M & PG
溫度范圍：-20℃~+105℃
IP 等級：IP 66
阻燃等級：UL94 V-0, UL94 V-2
抗 UV：有
環保：符合 RoHs, 不含鹵素
認證：cURus (E491228), CE
備注：PG,M牙無UL認證
規格表：
M 螺紋
| 公稱尺寸 | 公稱尺寸 | M螺紋 | 產品型號 | 每箱數量 (pcs) | 每箱重量 (kg) |
| 10 | 1/4 | M12 | FN5010-M12-V0 | 660 | 8.3 |
| 13 | 5/16 | M16 | FN5013-M16-V0 | 400 | 7.7 |
| 16 | 3/8 | M16 | FN5016- M16-V0 | 300 | 7.4 |
| 21 | 1/2 | M20 | FN5021-M20-V0 | 240 | 6.7 |
| 28 | 3/4 | M25 | FN5028-M25-V0 | 150 | 6.2 |
| 34 | 1 | M32 | FN5034-M32-V0 | 120 | 5.2 |
| 42 | 1-1/4 | M40 | FN5042-M40-V0 | 60 | 4.9 |
| 48 | 1-1/2 | M50 | FN5048-M50-V0 | 40 | 4.7 |
| 54 | 2 | M63 | FN5054-M63-V0 | 54 | 4.1 |
PG 螺紋
| 公稱尺寸 | 公稱尺寸 | PG螺紋 | 產品型號 | 每箱數量 (pcs) | 每箱重量 (kg) |
| 10 | 1/4 | PG7 | FN5010-PG7-V0 | 660 | 8.3 |
| 13 | 5/16 | PG9 | FN5013-PG9-V0 | 400 | 7.7 |
| 16 | 3/8 | PG11 | FN5016-PG11-V0 | 300 | 7.4 |
| 21 | 1/2 | PG16 | FN5021-PG16-V0 | 240 | 6.7 |
| 28 | 3/4 | PG21 | FN5028-PG21-V0 | 150 | 6.2 |
| 34 | 1 | PG29 | FN5034-PG29-V0 | 120 | 5.2 |
| 42 | 1-/14 | PG36 | FN5042-PG36-V0 | 60 | 4.9 |
| 48 | 1-1/2 | PG42 | FN5048-PG42-V0 | 40 | 4.7 |
| 54 | 2 | PG48 | FN5054-PG48-V0 | 54 | 4.1 |
NPT 螺紋
| 公稱尺寸 | 公稱尺寸 | NPT 螺紋 | 產品型號 | 每箱數量 (pcs) | 每箱重量 (kg) |
| 10 | 1/4 | NPT1/4" | FN5010-NPT1/4-V0 | 660 | 8.3 |
| 13 | 5/16 | NTP3/8" | FN5013-NPT3/8-V0 | 400 | 7.7 |
| 16 | 3/8 | NPT 1/2" | FN5016-NPT1/2-V0 | 300 | 7.4 |
| 21 | 1/3 | NPT 1/2" | FN5021-NPT1/2-V0 | 240 | 6.7 |
| 28 | 3/4 | NPT 3/4" | FN5028-NPT3/4-V0 | 150 | 6.2 |
| 34 | 1 | NPT 1" | FN5034-NPT1-V0 | 120 | 5.2 |
| 42 | 1-1/4 | NPT 1-1/4" | FN5042-NPT1-1/4-V0 | 60 | 4.9 |
| 48 | 1-1/2 | NPT 1-1/2" | FN5048-NPT1-1/2-V0 | 40 | 4.7 |
| 54 | 2 | NPT 2" | FN5054-NPT2-V0 | 54 | 4.1 |
